TRL-40(a) RCCB

TRL-40(a) RCCB

TRL-40(a) RCCB

    Share:

Product type: TRL-40(a)
Protection: Ground fault
Rated current(A): 16A, 20A, 25A, 32A

Description




Technical

TRL-40 series RCCB
Product type TRL-40(a)
Protection Ground fault
Rated current(A), In 16A, 20A, 25A, 32A, 40A
Rated residual current Operating, IΔn(mA) 15mA, 30mA
Non-operating, IΔno(mA) 7.5mA, 15mA
Poles 2 poles
Rated voltage(V), Ue 110V AC, 220V AC
Residual current off-time 0.1 s
Standard IEC/EN 61008-1, GB16916.1
Type of trip Ground fault Electronic
Rated Short Circuit Breaking capacity(kA) 2 kA
Endurance Electrical life 1000 operations
Mechanical life 2000 operations
Material of body Base Plastic
Cover in grey color Plastic
Cover in black color Bakelite
Type of operation AC
Length*Width*Height(mm) 70mm*32mm*51mm
